| Pager |
The pager control manages the automatic scrolling of its child controls. This can be created within a dialog, panel or box control. It can contain a toolbar, rebar, panel, tab, box, image, pager, @window or dialog control.
|
| Control Styles |
| These control styles are available when creating a Pager control. Remember that the general styles disabled, group, hidden, notheme, tabstop and transparent apply to all DCX controls except the embedded Dialog and Window controls. |
| autoscroll |
Causes the control to scroll when the mouse is over the scroll button. |
| horizontal |
Sets the pager control as horizontal. (Default is vertical) |
| /xdid flags |
| Control commands are input to the control with the /xdid command. |
|
/xdid -b |
| This command lets you sets border width. |
| Syntax: |
/xdid -b [DNAME] [ID] [WIDTH] |
| Example: |
/xdid -b dcx 4 100 |
|
/xdid -c |
| This command lets you create a single child control. |
| Syntax: |
/xdid -c [DNAME] [ID] [CID] [CONTROL] [X] [Y] [W] [H] (OPTIONS) |
| Example: |
/xdid -c dcx 4 12 rebar 10 10 400 25 tabstop |
| Parameters: |
| CID |
Unique control ID for the DCX Control. |
| CONTROL |
The type of DCX Control to create. Values can be:
toolbar
box, image
pager, panel, rebar, tab
dialog or window.
|
| X |
X position of control. |
| Y |
Y position of control. |
| W |
Width of control. |
| H |
Height of control. |
| OPTIONS |
Optional styles and options available on each individual controls. |
| | | Note. If docking a mIRC @Window or mIRC Dialog, the first parameter in OPTIONS must be the @window/dialog name. |
|
/xdid -d |
| This command lets delete the child control. |
| Syntax: |
/xdid -d [DNAME] [ID] [CID] |
| Example: |
/xdid -d dcx 4 12 |
| Parameters: |
| CID |
Control ID for the DCX Control. |
|
/xdid -s |
| This command lets you set the scroll button size. |
| Syntax: |
/xdid -s [DNAME] [ID] [SIZE] |
| Example: |
/xdid -s dcx 4 10 |
| Parameters: |
| SIZE |
Size of the scroll button. |
|
/xdid -t |
| This command lets sets the background and scroll button color. |
| Syntax: |
/xdid -t [DNAME] [ID] [COLOR] |
| Example: |
/xdid -t dcx 4 $rgb(255,0,255) |
|
/xdid -z |
| This command the pager to recalculate its size. This should be done after adding a button to a toolbar child control. |
| Syntax: |
/xdid -z [DNAME] [ID] |
| Example: |
/xdid -z dcx 4 |
| $xdid() Properties |
| The $xdid identifier is a given mIRC alias that communicates with the DCX DLL to extract information in DCX controls. |
|
$xdid().border |
| This property lets you retreive border size. |
| Syntax: |
$xdid(dialog, ID).border |
| Example: |
$xdid(dcx, 4).border |
|
$xdid().bsize |
| This property lets you retreive the button size. |
| Syntax: |
$xdid(dialog, ID).bsize |
| Example: |
$xdid(dcx, 4).bsize |
|
$xdid().color |
| This property lets you retreive the background color. |
| Syntax: |
$xdid(dialog, ID).color |
| Example: |
$xdid(dcx, 4).color |
| Pager Events |
| These events are fired when activity occurs in the Pager control. |
|
help |
| Launched when you click on a control using the ? contexthelp button. |
| Syntax: |
/cb_alias DNAME help ID |
| Example: |
/cb_alias dcx help 4 |
|
